Pneumatic Radial Riveting Machine JM6TQ
Spin Riveting Machine
Desktop type
|
Model：JM6TQ |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ■Desktop type, Handy size, Lightweight | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ■Max. riveting diameter 6mm(solid steel rivet) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ■Pneumatic driven, Stepless pressure regulation, Bi-directional speed adjustable | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ■Safty cover at rotating part for protection | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ■Widen workbench with T shape positioning hole, powerhead lifting adjustable. | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ■Adjustable riveting time, Mode selection: Auto/Manual | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ■Electric control box equipped with fully functional LCD screen | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ■Air filter and dryer, spraying lubrication | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Application Scope：Instrument and gauges,Sensitive electrical or electronic components, Daily hardware, etc. | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
JM6TQ |
可加高\加长\加宽改装 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
JM6TQ Pneumatic Radial Riveting Machine is developed on the basis of JM6T, it is medium size, desktop radial riveting machine driven by Pneumatic power, it adopted the latest technology 11 disc plum radial structure. The machine increases the workbench area with fixture groove, the spindle axis is coaxial with workbench center hole for the workpiece holding and positioning. The one-way regulating valve is applied to hydraulic pipe for controlling the riveting speed effectively. The powerhead apply screw lifting system to perform the rough adjusting. The double air regulators can be used to control riveting speed effectively and the air hose equipped with air filter for preventing moisture. Electric control units are equipped with digital display time relay and counter for easy operation. The best quality of all units on this machine ensure the smooth surface of workpiece and stability of processing. |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
 |
 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| JM6TQ | BACK OF JM6TQ | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video--Testing of Radial Riveting Machine
The qualified Radial riveting machine must should have slow and stability rotary of powerhead movement, as well must should be low noise.Let's watch this video about our products.
High Definition Video, Please ckick Video--Testing of Radial Riveting Machine
| Upgrade project | |||
 |
 |
 |
 |
| Micro adjusting index | Automatic lubricator | Integration control panel | PLC pressure monitor |
Service Promise
We will practice our commitment to customers, and strive to make customers trust of purchase, we guarantee to provide customers needs.
Service Items
Free technical guidance. Free sample riveting. Free mail specimen.
Equipment quality issues will be replaced or free maintenance service.
Free to change brand new same model of equipment within one year if major fault occure under normal operation, the major faults should must be follow warranty terms and conditions.
Whole-life serviceWarranty of riveting machine also provide after-sales service, only charge you for service and replacement parts cost.
48 hours on-site emergency maintenance For purchasing more than 5 sets machines of customers, on-site maintenance services carry out within 48 hours for major problems during the warranty period.(See Instruction Manual).Non- warranty period should charge for the maintenance.
